Synergy Jeep JK Weld-On Rear Track Bar Bracket
This a gusset kit designed to strengthen and reinforce the stock frame side front lower control arm mounts which are prone to damage when off road.
Features:
- Synergy JK Weld-On Rear Track-Bar Bracket
- Weld-On rear track-bar bracket designed to replace the weak factory JK track bar bracket
- Replace the thin factory brackets on a stock axle or use for swapping any axle into a JK
- Multiple Track-bar holes for suspension adjustments
- Designed to fit stock JK axle tubes, 3.150" diameter
- Will fit other diameter axle tubes with minor trimming
- Track bar relocation bolt holes are 2.900", 3.713", and 4.525" above the stock track bar mounting location.
Note: Requires the use of a minimum 3" bump stop spacer
Note: This bracket requires the use of a minimum 3" rear bump stop spacer for clearance with the exhaust. When using a lower relocation bolt hole or aftermarket exhaust, a shorter bump stop spacer may be used
